Do It Yourself Stalls

Our horse stall fronts and divider kits give you everything you need to assemble your own horse stalls. Our horse stalls are built to give you years of daily trouble free use!

OUR HORSE STALLS ARE BUILT TO GIVE YOU YEARS OF DAILY TROUBLE FREE USE!

Steel Grills
Our horse stall grills are 7/8″ outside diameter schedule 40 11 gauge steel with a wall thickness of .109″. “We believe our stall bars are the heaviest bars used in the horse stall manufacturing industry”. Our bars are welded in place 4 inches on center giving a space of approximately 3.25 inches between the bars. The steel tubing in our horse stalls and grills will not turn or rattle. These bars do not give when pushed on.

Wood
Our stalls come with the wood included. The wood we use in our stalls is a number 1 grade 8 inch tongue and groove v groove southern yellow pine. The wood is clear and free of knots and is not treated or finished, it will be up to you to stain or finish the wood after you have installed the stalls in your barn. The wood can be installed either vertically or horizontally within the steel stall frame your choice just let us know at the time you place your order. The wood on our stalls comes up 4 feet high unless you order all wood dividers then it will go all the way up the divider.

Powder Coated Steel Frames
We offer powder coated stall frames and grills. Powder coating leaves a much harder durable finish and will extend the life of your stalls finish. Black is the standard color but we can powder coat pretty much to the color you choose. Metal on all of our stalls is sand blasted and cleaned prior to powder coating.

Our Arched Steel Framed Horse Stalls Can Be Either Conventional, Free Standing, Or Modular!

If your barn does not have posts not a problem. Our fronts and dividers can attach to each other with heavy duty 1 inch diameter by 7″ long solid steel pins. Our stalls can easily be free standing or modular stalls depending on your barn situation.
At the time you place your order we can discuss how your stalls will attach to your barn walls or posts or to no posts at all.

Below Are Standard Sizes But We Will Make Stalls To The Exact Size You Need!

Stall Fronts

8′ Wide – $695
10′ Wide – $790
12′ Wide – $890
14′ Wide – $990
16′ Wide – $1085
20′ Wide – $1240

Whats Included In Stall Front Kits

  • 1 – SSD Sliding Horse Stall Door with Boards

  • 1 – 8′ Sliding Horse Stall Door Kit – 51″ x 88″ Door – Includes 8′ track, 2 – trollies, 2 – stop / guides, 1- horse shoe latch

  • 1 – 3′ Tall Steel Grill

  • 10 – 2″ x 8″ V Groove Boards

  • 1 – 2 x 6 For Top Board

Below Are Standard Sizes We Make But We Will Make Stalls To The Exact Size You Need!

Stall Dividers
( Stall Grill and Wood )

8′ Wide – $445
10′ Wide – $535
12′ Wide – $640
14′ Wide – $750
16′ Wide – $855
20′ Wide – $1075

Whats Included in Stall Divider Kits

  • 1 – 3′ Tall Steel Grill or extra boards if you want all wood dividers

  • 9 – 2″ x 8″ V Groove Boards

Options Available For These Stalls

  • Swing Out Hay and Grain Feeder

  • Swing Out Bucket Rack

  • Steel Horse Stall Corner Grain Feeder

  • Swing Out Corner Grain Feeder

  • Thru The Wall Grain Feeder

  • 10″ x 10″ Feed Opening

  • 20″ x 40″ Grilled Swing Open Feed Door

  • Arched Drop Down In The Stall Door

Pickup at our Fabrication is FREE. Delivery is $3.00 a mile from 47872

Horse Stall Installation Service

If you need us to professionally install your new horse stalls we can do that. Our charge for doing installations depends on location and the number and type of stalls you need installed. Installation also requires us to deliver your stalls to your location.

How To Contact Us For Pre-Sales Questions

  • Email us your questions using the form on our contact page and we will get right back to you within 24 hours during normal business hours M-F from 8-5 eastern time.

How To Place an Order

  • Call our sales office at 888-568-2035 from 8-5 eastern time M-F.

  • Email us letting us know you are ready to place an order and give us a good phone number to call you back and a salesperson will call you and help you with placing your order with us.

  • Send us an email with your name, delivery/shipping address, phone number, quantity and descriptions including color of the items you want to order. Once we receive your order we will make an invoice and email it to you. The invoice can then be paid directly from the invoice by e-check directly from your checking account or you may mail us a personal check, business check, cashiers check, or money order along with a copy of your invoice to pay for your order.
